Automatic Mask Melt-blown Nonwoven Extrusion Machine Face Mask
Making Machine
The PP melt blown nonwoven production line is a polymer melt
extruded from a screw extruder. The polymer is extremely stretched
by high-speed hot air or other means to form very fine short
fibers, which are aggregated to A web is formed on a roller or a
screen curtain, and is finally reinforced by self-adhesion or
thermal bonding. Its unique properties are widely used in mask
filter materials, thermal insulation filling materials, medical
health materials, wiping materials, etc. The finished product can
pass the N95 standard as the core material of the mask.
1, Machine Specifications
| Pattern | 1600mm-SJφ90mm |
| Length-diameter ratio: | 32:1 |
| Products gram: | 20-200g/㎡ |
| Final product width: | 1580mm(After deburring) |
| Suitable material: | PP |
| Max output | 260Kg/h |
| Installation capacity | About 580KW |
| Production of energy consumption | About 360KW / h |
| Machine weight | About 18 Ton |
| Winding load weight | 600Kg |
| Max line speed | 60m/min |
| Capacity | 1500-2000kg/24H |
| Power | 380V/50HZ/3 phase |
2, Process of meltblown nonwoven production line
Polymer preparation --- Melt extrusion --- Metering pump ---
Meltblown die head assembly --- Solution thin-flow drawing ---
Fiber cooling --- Auxiliary network --- Electrostatic electret ---
Reinforced finished product
Melt-blown cloth is produced by melt-blown process. The equipment
mainly includes: screw extruder, melt pump, screen changer,
melt-blown device, winding device, air system (hot air blower and
heater), etc. The function of the screw extruder is to melt the
slice material; the role of the melt pump is to accurately measure,
control the output and the fineness of the fiber, and continuously
and evenly transfer the melt to the spinneret. The function of the
screen changer is to filter out impurities in the melt so as not to
block the spinneret holes. The function of the winding device is to
pack the meltblown cloth into rolls. The function of the air system
(hot air blower and heater) is to provide the temperature and
pressure of the hot air used in the drawing of the spinning air
stream.
3, Machine Pictures
Good after-sales service:
(1) The warranty of main gearbox is extended for free for three
years;
(2) Modernized CNC processing equipment to fundamentally guarantee
the supply of quantity and quality of equipment spare parts;
(3) We provide free engineers overseas installation service.
FAQ:
1. Are you factory or trading company?
We are factory with export rights. We manufacture machines and
export to customers by ourself.
2. Which payment term is accepted?
30% in advanced payment+70% payment paid before shipment.
Welcome your inspection before shipment.
